Example 11: Mars Colony — Multi-System Autonomous Control¶
The capstone. 70+ fields across 6 subsystems with hub-spoke connectivity. Cascading failure prediction through cross-system reasoning — something a per-subsystem model structurally cannot do.
Source: examples/11_mars_colony.py
Results¶
Top left: Canvas layout — six subsystems (life support, power, thermal, comms, ISRU, crew) with hub-spoke colony-level coordination.
Top right: Failure prediction accuracy by subsystem — Greenhouse 100%, Life Support 66%, Power 59%, ISRU 50%, overall 90.4%.
Bottom left: Cross-system correlations (learned) — heatmap shows the model discovers inter-subsystem dependencies, with strongest coupling between power and life support.
Bottom right: Training curves — alert loss, subsystem loss, and total loss over 500 epochs.
What it demonstrates¶
- Six-subsystem hierarchy — life support, power, thermal, communications, ISRU, crew
- Cross-system cascading failures — a power anomaly propagates to thermal, then life support; the model must route through these connections
- Hub-spoke colony-level coordination — colony-level fields see all subsystems; subsystems see each other only through the hub
- Crew psychological state — stress, fatigue, morale as first-class fields that affect mission-critical decisions
Type hierarchy (partial)¶
@dataclass
class LifeSupport:
atmosphere: Field = Field(2, 4, period=1) # O2, CO2, pressure, humidity
water_loop: Field = Field(1, 4, period=2)
food_stores: Field = Field(1, 2, period=60)
lss_health: Field = Field(1, 1, loss_weight=5.0)
@dataclass
class PowerSystem:
solar_output: Field = Field(2, 4, period=1)
battery_state: Field = Field(1, 4, period=1)
load_distribution: Field = Field(2, 4, period=1)
power_health: Field = Field(1, 1, loss_weight=4.0)
@dataclass
class CrewState:
physical_health: Field = Field(2, 4, period=4)
psychological: Field = Field(2, 4, period=8)
workload: Field = Field(1, 2, period=2)
morale: Field = Field(1, 1, period=8)
@dataclass
class MarsColony:
life_support: LifeSupport = field(default_factory=LifeSupport)
power: PowerSystem = field(default_factory=PowerSystem)
thermal: ThermalControl = field(default_factory=ThermalControl)
comms: Communications = field(default_factory=Communications)
isru: ISRU = field(default_factory=ISRU)
crew: CrewState = field(default_factory=CrewState)
mission_health: Field = Field(1, 1, loss_weight=3.0) # colony-level
abort_risk: Field = Field(1, 1, loss_weight=10.0) # evacuation signal
Hub-spoke cross-system reasoning¶
bound = compile_schema(
MarsColony(), T=4, H=16, W=16, d_model=128,
connectivity=ConnectivityPolicy(
intra="dense",
parent_child="hub_spoke", # mission_health sees everything
),
)
Each subsystem's _health field attends to all fields within its subsystem. The colony-level mission_health and abort_risk attend to all _health fields. This two-level hub-spoke forces cascading failure information to propagate upward through the hierarchy — not shortcut through a flat dense connection.
Ablation: can a flat model predict cascading failures?¶
A flat model trained on colony data learns statistical correlations between subsystems but has no mechanism to trace the causal path. The canvas model, forced by topology, learns the pathway. The ablation plots the failure prediction recall broken down by failure origin — single-system vs cascading — where the topology advantage is largest for cascades.
Task spec
Full implementation details in examples/tasks/11_mars_colony.md.
